Overview
Differences - Laguna 14 bx & 14|12
- Weight increased
- Solid one-piece Frame
- Frame is heavier Gauge
- Magnetic On/Off Switch
- Disc-Brake w/ Micro-Switch
- Dual light mounting positions
Get Yours Today at OakTree Supplies!
110
- 1.75 HP, 14 Amp, TEFC
- 110 Volt Outlet for Light
- 6 ft. Cord w/ Nema Plug: 5-15P
- Weight (Net/Ship): 260/320 Lbs.
220
- 1 Phase, 2.5HP, 9.8Amp, TEFC
- 220 Volt Outlet for Light
- 6 ft. Cord w/Nema Plug: 6-15P
- Weight (Net/Ship): 270/330 Lbs
Specifications
- 12” Resaw
- Height: 70 ¼”
- 21 ½” X 16” Table
- Table Height: 38”
- 7° Table Tilt Left
- 2 X 4” Dust Ports
- Blade Length: 115”
- Cast Iron Wheels
- Magnetic Starter
- Dual Light Mount
- 45° Table Tilt Right
- Max. Blade Width: ¾”
- Pyramid-Shaped Spine
- Min. Blade Width: 1/8”
- Footprint: 17 ½” X 22 ½”
- Quick Release Tension
- Magnetic Blade Guard
- Laguna Ceramic Guides
- Hi/Low aluminum Fence
- Worm Gear Rack & Pinion
- Massive Cast Trunion 8”X13”
