SCM Minimax FS 41ES - Tersa Jointer/Planer (Single-Phase)

Price
$ 14,395

Have questions? Give us a call at 260-637-0054.

  • Freight included in price*
  • Next available March 2024

The Minimax FS 41ES X is a professional grade, heavy duty, long bed jointer/planer combination machine designed to meet the needs of the most demanding environments. It features cast iron tables, a 4.8 horsepower single-phase motor and a tilting fence.

The planer unit stands on cast iron supports and the standard version has a 95 mm diameter “Tersa” cutter block with 4 quick tightening knives and automatic adjustment. For an impeccable finish, the pressure of the thicknesser feed rollers can be adjusted according to the type of wood machined. The infeed roller has a helicoidal profile to guarantee firm and constant work piece feed, while the outfeed roller, in sandblasted steel, maintains the perfect post-processing finishing.

The standard guard offered on the Minimax jointer/planer combination machine is a spring type guard which always covers the unused portion of the knife. Other style guards require the guard to be manually moved into place when the fence is readjusted. When processing thick wood, this does not cover the blade as completely.

For a maximum long lasting stability, the cast iron thicknessing table lifts on 4 spindles with trapezoidal threads dust protected. The Minimax FS 41ES uses a dedicated planing fence extremely rigid and smooth, thanks to a support with central round bar.

The ES series adopts ergonomic solutions like the 87" jointer tables, in ribbed cast iron, that allows for the simultaneous opening towards the inside of the machine with a 90° angle. For maximum long lasting stability the cast iron thicknessing tables lift on 4 spindles with dust protected trapezoidal threads.

Features
  • 4.8hp motor single-phase (1x230v)
  • Parallelogram jointer tables
  • 4 post planer table
  • Digital-mechanical readout on planer height
  • LED readouts & powered movements available on request (3ph machine)
  • 4-knife “Tersa” jointer/planer cutterhead & 4 post planer bed support
  • American-style jointer guard
  • Wheels for machine movement
Specs

Exhaust outlet diameter: 4.72" (120 mm)
Electrical: Single-phase, 230V
Motor: 4.8hp

Dust collection: 1,000 CFM
Net weight: 1,285 lbs.

Jointer
Working width: 16” (410 mm)
Overall table length: 87” (2,200 mm)
Cutterhead diameter: 4" (102 mm)
Cutterhead speed: 5,000 RPM
Max. depth of cut: 0.1875" (4.8 mm)
Fence tilt: 0° - 45°

Planer
Table Size: 16.125” x 30.5” (410 mm x 775 mm)
Max. working thickness: 9.44” (240 mm)
Min. working thickness: 0.125” (3 mm)
Max. stock removal: 1/8" (5 mm)
Feed speeds: 23 & 46 fpm

Video

*Shipping

Please note: Items being shipped to extremely remote areas or areas with limited delivery access (such as islands only accessible by ferry) may incur additional shipping or freight fees. If your order requires any additional fees other than what is already included in the price, you will be contacted before those fees are applied and before your item ships. This is rare and will not apply to most orders.

SKU: FS 41ES - T - 1ph
